Daikin FXMQ25PVE [6/20] Control systems
![Daikin FXMQ25PVE [6/20] Control systems](/views2/1702321/page6/bg6.png)
•VRV
®
Systems • Indoor Units
135
• Indoor Units • CONCEALED CEILING UNIT • FXMQ-PVE
4 Control systems
FXMQ-P
3D060455
No.
Type
Item
FXMQ~PVE
1 Remote control
Wireless
H/P
C/O
BRC4C65
BRC4C66
Wired BRC1D52
2 Simplified remote control BRC2C51
3 Remote control for hotel use BRC3A61
4 Adaptor for wiring KRP1C64
5-1 Wiring adaptor for electrical appendices (1) KRP2A61
5-1 Wiring adaptor for electrical appendices (2) KRP4AA51
6 Remote sensor KRCS01-1B
7 Mounting plate for adapter PCB
Note 2, 3
KRP4A96
8 Central remote control DCS302CA61
8-1 Electrical box with earth terminal (3 blocks) KJB311AA
9 Unified on/off control DSC301BA61
9-1 Electrical box with earth terminal (2 blocks) KJB212AA
9-2
Noise filter
(for electromagnetic interface use only)
KEK26-1A
10 Schedule timer DST301BA61
11
External control adaptor for outdoor unit
(Must be installed on indoor units)
DTA104A61
NOTES
1 Mounting plate (No.7) is necessary for each adapter marked
.
2 Up to 2 adapters can be fixed for each mounting plate.
3 Only one mounting plate can be installed for each indoor unit.
