45W PWM Output LED Driver

ODLV-45 ser i e s

File Name:ODLV-45-SPEC 2017-07-21

ODLV-45 -12

ODLV-45 -24

ODLV-45 -36

ODLV-45 -48 ODLV-45 -60

SPECIFICATION

MODEL

OUTPUT

FREQUENCY RANGE

POWER FACTOR (Typ.)

EFFICIENCY (Typ.)

AC CURRENT (Typ.)

INPUT

INRUSH CURRENT(Typ.)

LEAKAGE CURRENT

SAFETY STANDARDS

WORKING HUMIDITY

STORAGE TEMP., HUMIDITY

TEMP. COEFFICIENT

VIBRATION

MTBF

DIMENSIONOTHERS

NOTE

PACKING

OVER CURRENT

47 ~ 63Hz

105 ~ 115%

20 ~ 90% RH non-condensing

-40 ~ +80℃, 10 ~ 95% RH

±0.03%/℃ (0 ~ 50℃)

10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes

ENVIRONMENT

SAFETY &

EMC

PROTECTION

EMC IMMUNITY

EMC EMISSION

WITHSTAND VOLTAGE

ISOLATION RESISTANCE

TOTAL HARMONIC DISTORTION

I/P-O/P:3.75KVAC

I/P-O/P:100M Ohms / 500VDC / 25℃/ 70% RH

±10%

0~100%

84%

86%

88%

88% 90%

0.6A / 115VAC 0.4A / 230VAC 0.3A / 277VAC

<0.75mA / 277VAC

111*77*28.5mm (L*W*H)

0.42Kg;24pcs/11Kg/ 0.72CUFT

SHORT CIRCUIT

DIMMING RANGE

DC VOLTAGE

RATED POWER

SETUP TIME Note.3

VOLTAGE TOLERANCE

VOLTAGE RANGE Note.2

1KHz(±20%)

500ms / 230VAC 1200ms/115VAC

12V

24V

36V

48V 60V

3.0A

1.88A

1.25A

0.94A

36W

45.12W

45W

45.12W

0.75A

45W

PWM FREQUENCY (Typ.)

AUXILIARY DC OUTPUT Note.4

Nominal 12V(deviation 11.4~12.6)@50mA for A-Type only

(Please refer to "STATIC CHARACTERISTIC" section)

90 ~ 295VAC 127 ~ 417VDC

PF>0.95/115VAC, PF>0.92/230VAC, PF>0.9/277VAC@full load

(Please refer to "POWER FACTOR (PF) CHARACTERISTIC" section)

THD< 20%(@load≧60%/115VAC,230VAC; @load≧75%/277VAC)

(Please refer to “TOTAL HARMONIC DISTORTION” section)

COLD START 30A(twidth=150 s measured at 50% Ipeak) at 230VACμ ; Per NEMA 410

<0.5W for Blank-Type, <1.2W for A-Type

NO LOAD POWER CONSUMPTION

WORKING TEMP.

MAX. CASE TEMP.

Tcase=-20 ~ +85℃ (Please refer to “ OUTPUT LOAD vs TEMPERATURE” section)

Tcase=+85℃

UL8750(type"HL"),CSA C22.2 NO.250.13-12;ENEC EN61347-1 & EN61347-2-13 independent, EN62384,GB19510.1,GB19510.14;

Compliance to EN55015, EN61000-3-2 Class C (@load≧60%) ; EN61000-3-3,GB17743,GB17625.1

Compliance to EN61000-4-2,3,4,5,6,8,11; EN61547, light industry level(surge immunity:Line-Line:1KV)

1.AllparametersNOTspeciallymentionedaremeasuredat230VACinput,ratedcurrentand25 ofambienttemperature.℃

2.De-ratingmaybeneededunderlowinputvoltages.Pleasereferto“STATICCHARACTERISTIC”sectionsfordetails.

3.Lengthofsetuptimeismeasuredatcoldfirststart.TurningON/OFFthedrivermayleadtoincreaseofthesetuptime.

4.ThereisnodesignofshortcircuitprotectionfortheAuxiliaryDCoutput;thisfunctioncannotbeusedwhendimminginputterminals(DIM+,DIM-)

areshortcircuitorwhenitisnoloadorshortcircuitatoutput(Vo+,Vo-).

5.Thedriverisconsideredasacomponentthatwillbeoperatedincombinationwithfinalequipment.SinceEMCperformancewillbe

affectedbythecompleteinstallation,thefinalequipmentmanufacturersmustre-qualifyEMCDirectiveonthecompleteinstallationagain.

MAX. No. of PSUs on 16A

CIRCUIT BREAKER

32 units (circuit breaker of type B) / 32 units (circuit breaker of type C) at 230VAC

Protection type : Hiccup mode, recovers automatically after fault condition is removed

RATED CURRENT

IP67 approved

388.02K hrs min. MIL-HDBK-217F (25℃)

Shut down O/P voltage, re-power on to recovery
