File Name:ODLV-45-SPEC 2017-07-21

ODLV-45 ser i e s

45W PWM Output LED Driver

MECHANICAL SPECIFICATION

Case No.ODL-45A Unit:mm

Vo+(Red)

Vo-(Black)

DIM+(Purple)

DIM-(Gray)

ACL(Brown)

ACN(Blue)

Vo+(Red)

Vo-(Black)

DIM+(Purple)

DIM-(Gray)

UL1007 22AWG

UL1007 18AWG

SVT 18AWG

AC wire No. Assignment(AC IN) DC wire No. Assignment(DC OUT)

ACL(Brown)

ACN(Blue)

※Blank-Type:

※A-Type:

AUX+(Yellow)

AUX-(Green)

Vo+(Red)

Vo-(Black)

DIM+(Purple)

DIM-(Gray)

ACL(Brown)

ACN(Blue)

AUX+(Yellow)

AUX-(Green)

Vo+(Red)

Vo-(Black)

DIM+(Purple)

DIM-(Gray)

UL1007 22AWG

UL1007 18AWG

AC wire No. Assignment(AC IN) DC wire No. Assignment(DC OUT)

111

3.5

28.5

2.5

150±10

200±10

150±10

200±10

111

3.5

28.5

2.5

200±10

150±10

200±10

ACL(Brown)

ACN(Blue)

SVT 18AWG

INSTALLATION MANUAL

Please refer to : http://www.meanwell.com/manual.html

‧ : Max. Case Temperature

2*ψ4.5
