MEAN WELL XLG-100-H-AB Datasheet онлайн
100W Constant Power Mode LED Driver
XLG-100 series
M M
110
SELV
Type HL
Note.12
■ Description
■ Features ■ Applications
■ Model Encoding
XLG - 100
Rated wattage
Series name
AB
Type
A
L
Rated output voltage(12/24V or L/H types)
Function options
-
(0~10Vdc, 10V PWM signal and resistance)
In Stock
Function
Note
In Stock
Io adjustable via built-in potentiometer
Io adjustable via built-in potentiometer +3 in 1 dimming function
｛
I: for India version
:For standard version
I
-
File Name:XLG-100-SPEC 2019-04-09
Blank
By request
Io and Vo fixed. (For harsh environment)
Note.12
Note: 12V and 24V models without the typeAB
•Skyscraper lighting
Street lighting
•
Floodlight Lighting•
Stage lighting•
•
Fishing lighting
Horticulture lighting
•
•
Bay lighting
DMX power supply
•
Type for use in class , Division 2HL Ⅰ•
•
Wide input range 100~305V ( Class )AC Ⅰ
•Full power output at 70~100% Constant power mode operation
•Metal case with P67, suitable for outdoor applicationI
•LVLE (H type/24V) Class 2 (24V) power unit
•Surge protection with 6KV/4KV (10KV/6KV optional)
•3 in 1 dimming function (Dim to off and Isolation design)
•India ( ) version with Input Over Voltage ProtectionEESL can
survive input voltage stress of 440Vac for 48 hours
•Protection functions: / / /OVP SCP OCP OTP
•Life time >50,000 hrs. and 5 years warranty
XLG LED AC DC XLG-100 series is a 100W / driver featuring the constant power mode. -100 operates
from 100~305 and offers models with different rated current ranging between 700mA and 8000mA.VAC
Thanks to the high efficiency up to 92% , with the fanless design, the entire series is able to operate for
-40 ~+90 case temperature under free air convection. The design of metal housing and 67 ingressIP
℃℃
protection level allows this series to fit both indoor and outdoor applications. Moreover the innovative
environment-adaptive capability allows this series to reliably light on the s for all kinds of applicationLED
environments in almost any spots that may install luminaires in the world. -100series complyLED XLG
with the latest version of IEC61347/GB7000.1-2015 and UL8750 international safety regulations. The
output and dimming are also completely in accordance with the new regulations with isolation tocircuit
ensure the user and luminaire system during installation.safety of both
