MEAN WELL XLG-100-H-AB [4/9] In the constant current
![MEAN WELL XLG-100-H-AB [4/9] In the constant current](/views2/1705851/page4/bg4.png)
20V
25V
30V
35V
40V
45V
50V
55V
60V
0mA 500mA 1000mA 1500mA 2000mA 2500mA 3000mA
1750mA,56V
875mA,56V
1750mA,27V 2800mA,27V
2780mA,36V
BLOCK DIAGRAM
PFC fosc : 50~120KHz
PWM fosc : 60~130KHz
350mA, 142V
700mA, 142V
1050mA, 95V
1050mA, 71V700mA, 71V
60V
70V
80V
90V
100V
110V
120V
130V
140V
150V
0mA 200mA 400mA 600mA 800mA 1000mA 1200mA
100W Constant Power Mode LED Driver
XLG-100 series
File Name:XLG-100-SPEC 2019-04-09
DIM+
DIM-
(AB Type)
DETECTION
PWM
CIRCUIT
O.L.P.
EMI FILTER
RECTIFIERS
POWER
SWITCHING
FILTER
&
RECTIFIERS
+V
-V
I/P
FG
CONTROL
O.V.P.
&
O.C.P.
PFC
CIRCUIT
PFC
CONTROL
DRIVING METHODS OF LED MODULE
※ -I V Operating Area
◎ XLG-100-L
Recommend Performance Region
Recommend Performance Region
◎ XLG-100-H
O.T.P.
◎ XLG-100-12,24
※ This series is able to work in either Constant Current mode (a
direct drive way) or Constant Voltage mode (usually through
additional DC/DC driver) to drive the LEDs.
Typical output current normalized by rated current (%)
100
60
(min.)
Vo(%)
50
100
Io(%)
(B)
Constant
Current area
(C)
Hiccup
Protection
(A)
Constant
V areaoltage
In the constant current
depends on the configuration
Should there be any
at the output of the driver
region, the highest voltage
of the end systems.
compatibility issues, please
please contact MEAN WELL.
