MODEL
OUTPUT
VOLTAGE RANGE
Note.5
FREQUENCY RANGE
POWER FACTOR
EFFICIENCY (Typ.)
AC CURRENT
INPUT
INRUSH CURRENT(Typ.)
LEAKAGE CURRENT
EMC IMMUNITY
WORKING TEMP.
WORKING HUMIDITY
STORAGE TEMP., HUMIDITY
TEMP. COEFFICIENT
VIBRATION
OVER TEMPERATURE
OVER VOLTAGE
500ms, 100ms/230VAC, 1200ms, 100ms/115VAC
12ms/ 230VAC 12ms/ 115VAC
47 ~ 63Hz
1.1A / 115VAC 0.5A / 230VAC 0.42A/277VAC
<0.75mA / 277VAC
20 ~ 95% RH non-condensing
-40 ~ + , 10 ~ 95% RH90℃
±℃ ℃0.03%/ (0 ~ 60 )
10 ~ 500Hz, 5G 12min./1cycle, period for 72min. each along X, Y, Z axes
ENVIRONMENT
EMC EMISSION
SAFETY &
EMC
PROTECTION
Hiccup mode, recovers automatically after fault condition is removed
Shut down output voltage, re-power on to recover
SHORT CIRCUIT
I/P-O/P:4.2KVAC I/P-FG:2.1KVAC O/P-FG:1.5KVAC
I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25 / 70% RH℃
WITHSTAND VOLTAGE
ISOLATION RESISTANCE
TOTAL HARMONIC DISTORTION
DC VOLTAGE
RATED CURRENT
RATED POWER
LINE REGULATION
LOAD REGULATION
SETUP, RISE TIME
Note.6
HOLD UP TIME (Typ.)
RIPPLE & NOISE (max.)
Note.3
VOLTAGE TOLERANCE
Note.4
CONSTANT CURRENT REGION
Note.2
OVER CURRENT
COLD START 50A(twidth= s measured at 50% Ipeak) at 230VAC300μ;Per NEMA 410
MAX. No. of PSUs on 16A
CIRCUIT BREAKER
8units (circuit breaker of type B) / 14 units (circuit breaker of type C) at 230VAC
MAX. CASE TEMP.
Tcase=+90℃
(Please refer to "STATIC CHARACTERISTIC" section)
100 ~ 305VAC 142 ~ 431VDC
95 ~ 108%
Hiccup mode or Constant current limiting,
recovers automatically after fault condition is removed
Hiccup mode or Constant current limiting, recovers automatically after fault condition is removed
PF 0.97/115VAC, PF 0.95/230VAC, PF 0.92/277VAC@full load≧≧≧
THD< 10%(@load 50%/115VC,230VAC; @load 75%/277VAC)≧≧
Tcase=-40 ~ +90 (Please refer to “ OUTPUT LOAD vs TEMPERATURE” section)℃
XLG-100-12-
12V
8A
150mVp-p
8.4~ 12V
96W
±3.0%
±0.5%
±2%
92%
13.5 ~ 18V
SAFETY STANDARDS
UL8750 ENEC EN61347-1, EN61347-2-13 independent, EN62384(type”HL”), UL879, CSA C22.2 No. 250.13-12; ;
GB19510.1 GB19510.14, ; EAC TP TC 004; IP67 approved
XLG-100-24-
24V
4A
240mVp-p
16.8~ 24V
96W
±2.0%
±0.5%
±1%
92%
27 ~ 34V
NO LOAD
POWER CONSUMPTION
No load power consumption <0.5W(for standard version)
INPUT OVER VOLTAGE
Note.7
320 ~ 390 (Shut down output voltage when the input voltage exceeds protection voltage)VAC
can survive input voltage stress of 440Vac for 48 hours
CURRENT ADJ RANGE
2~4A
Parameter
Conducted
Radiated
Harmonic Current
Voltage Flicker
EN61547
Parameter
ESD
Radiated
EFT/Burst
Surge
Conducted
Magnetic Field
Voltage Dips and Interruptions
Standard
EN61000-3-2
EN61000-3-3
Standard
EN61000-4-2
EN61000-4-3
EN61000-4-4
EN61000-4-5
EN61000-4-6
EN61000-4-8
EN61000-4-11
Test Level/Note
-----
-----
Class C @load≥50%
-----
Test Level/Note
Level 3, 8KV air ; Level 2, 4KV contact
Level 3
Level 3
4KV/Line-Line 6KV/Line-Earth(6K/10K option)
Level 3
Level 4
>95% dip 0.5 periods, 30% dip 25 periods,
>95% interruptions 250 periods
EN55015(CISPR15)
EN55015(CISPR15)
MTBF
DIMENSIONOTHERS
NOTE
PACKING
1. All parameters NOT specially mentioned are measured at 230VAC input, rated and 25 of ambient temperature.current ℃
2. Please refer to "DRIVING METHODS OF LED MODULE".
3. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.
4. Tolerance : includes set up tolerance, line regulation and load regulation.
5. De rating may be needed under low input voltages. Please .- refer to STATIC CHARACTERISTIC sections for details
6. Length of set up time is measured at first cold start. Turning ON/OFF the driver may lead to increase of the set up time.
7. Only for XLG-100 I series
8. The driver is considered as a component that will be operated in combination with final equipment. Since EMC performance will be affected by the
complete installation, the final equipment manufacturers must re-qualify EMC Directive on the complete installation again.
9. The ambient temperature derating of 3.5 /1000m with fanless models and of 5 /1000m with fan models for operating altitude higher than 2000m(6500ft).℃℃
10. Please refer to the warranty statement on MEAN WELL's website at http://www.meanwell.com
11. This series meets the typical life expectancy of >50,000 hours of operation when Tcase, particularly tc point (or TMP, per DLC), is about 80 or less.
℃
12.Products sourced from the Americas regions may not have the PSE/CCC/BIS/KC logo. Please contact your MEAN WELL sales for more information.
13.For any application note and IP water proof function installation caution, please refer our user manual before using.
https://www.meanwell.com/Upload/PDF/LED_EN.pdf
1006.16K hrs min. Telcordia SR-332 (Bellcore) ; 276.37Khrs min. MIL-HDBK-217F (25 )℃
140 63**32mm (L*W*H)
0.58Kg;24pcs /15Kg /0.85CUFT
SPECIFICATION
File Name:XLG-100-SPEC 2019-04-09
100W Constant Power Mode DriverLED
XLG-100 series
4 ~ 8A
Adjustable for A/AB-Type only (via the built-in potentiometer)
