TRACO POWER TML15124C [2/6] Ac dc power modules

http://www.tracopower.com Page 2 of 6

All specifications valid at nominal input voltage, full load and +25°C after warm-up time unless otherwise stated.

AC/DC Power Modules

TML Series 5 to 30 Watt

Input Specifications

Input voltage ranges – AC input 90 – 264 VAC

– DC Input TML 30 models: 100 – 370 VDC

output power derating 1 %/V below 110 VDC

other models: 85 – 370 VDC

TML 30 models: 30 mA / 55 mA typ.

Input current full load 115 VAC / 230 VAC

TML 5 models: 120 mA / 70 mA max.

TML 10 models: 200 mA / 130 mA max.

TML 15 models: 310 mA / 170 mA max.

TML 30 models: 520 mA / 320 mA max.

External fuse (required) 1.5 A slow blow type (recommendation)

Order Code Output Power Output 1 Output 2 Output 3

PCB-mounting Chassis mounting max.

TML 15105 TML 15105C

24 VDC/625 mA

TML 15205 TML 15205C

15 Watt 5 VDC/1500 mA –5 VDC/1500 mA

TML 15212 TML 15212C

12 VDC/650 mA –12 VDC/650 mA

TML 15215 TML 15215C

15 VDC/500 mA –15 VDC/500 mA

TML 15512 TML 15512C

5 VDC/2000 mA 12 VDC/200 mA –12 VDC/200 mA

TML 15515 TML 15515C

12 VDC/2500 mA

TML 30115 TML 30115C

15 VDC/2000 mA

TML 30124 TML 30124C

24 VDC/1250 mA

TML 30205 TML 30205C

30 Watt 5 VDC/3000 mA –5 VDC/3000 mA

TML 30212 TML 30212C

12 VDC/1300 mA –12 VDC/1300 mA

TML 30215 TML 30215C

*5 VDC/3000 mA 15 VDC/500 mA –15 VDC/500 mA
