Page 6 of 6
Specifications can be changed without notice! Make sure you are using the latest documentation, downloadable at www.tracopower.com
www.tracopower.com
AC/DC Power Modules
TML Series 5 to 30 Watt
TML 30 Models
PCB mounting:
1
27
6
5
4
3
Bottom view
63.5
(2.50)
27.9 ±0.3
(
1.10
±0.012
)
3.8
(0.15)
81.3 ±0.3
(3.20
±0.012)
88.9
(3.50)
15.24
±0.3
(0.60
±0.012
)
12.7
±0.3
(0.50
±0.012
)
12.7
±0.3
(0.50
±0.012)
15.24
±0.3
(0.60
±0.012
)
25.0
(0.98)
6
(0.24)
27.9
±0.3
(
1.10
±0.012
)
Top view
1
2
7
6
5
4
3
31.0
(1.22)
5.5
(0.22)
64.7
(2.55)
50.0
±0.3
(
1.97
±0.012
)
6.0
(0.20)
100.0 ±0.3
(3.94
±0.012)
112.0
(4.41)
4 x ø3.5
(4 x ø0.14)
NC
TML 30-C Models
Chassis mounting:
Weight : 230 g (8.1 oz)
Pin diameter ø 1.0 mm
Weight : 275 g (9.7 oz)
Dimensions in[mm], () = Inches
Tolerances = 0.5mm (0.02)
Pin Single Dual sym.
Dual asym.
Triple
1
AC(N) AC(N) AC(N) AC(N)
2
AC(L) AC(L) AC(L) AC(L)
3
+V out +V out +V out 2 +V out 2
4
No Pin No Pin +V out 1 +V out 1
5
–V out Common –V out 2 Com. 2/3
6
No Pin No Pin –V out 1 –V out 1
7
NC. –V out NC. –V out 3
Pin-Out
Rev. March 23. 2016
Outline Dimensions
NC = Not to connect
