http://www.tracopower.com Page 5 of 6
AC/DC Power Modules
TML Series 5 to 30 Watt
Outline Dimensions
TML 15 Models
PCB mounting:
TML 15-C Models
Chassis mounting:
Bottom view
1
2
38
7
6
5
4
54.0
(2.13)
20.0
±0.3
(
0.79
±0.012
)
20.0
±0.3
(
0.79
±0.012
)
6.0
(0.24)
62.0 ±0.3
(2.44
±0.012)
74.0
(2.91)
8.5 ±0.3
(0.33
±0.012)
8.5 ±0.3
(0.33
±0.012
)
11.5
±0.3
(0.45
±0.012)
11.5 ±0.3
(0.45
±0.012)
22.0
(0.87)
10
(0.39)
Top view
54.0
(2.13)
5.0
(0.20)
86.0
±0.3
(3.39
±0.012
)
96.0
(3.78)
4 x ø3.5
(4 x ø0.14)
1
2
3
8
7
6
5
4
27.6
(1.08)
5.0
(0.20)
46.0
±0.3
(1.81
±0.012
)
Weight: 120 g (4.2 oz)
Pin diameter ø 1.0 mm
Weight: 150 g (5.3 oz)
Pin Single Dual Triple
1
FG FG FG
2
AC(N) AC(N) AC(N)
3
AC(L) AC(L) AC(L)
4
No Pin No Pin –V out 3
5
–V out –V out Com. 2/3
6
No Pin Common +V out 2
7
+V out +V out –V out 1
8
No Pin No Pin +V out 1
Pin-Out
