TPP 40 Series, 40 Watt

www.tracopower.com Page 3 of 5

All specifications valid at nominal input voltage, full load and +25°C after warm-up time unless otherwise stated.

General Specifications

Operating temperature –40°C to +85°C

with derating, see graph on p.4

Output power derating – Temperature single output: 2.67 %/K above +70°C at 230 VAC

2.75 %/K above +65°C at 115 VAC

multi output: 1.60 %/K above +60°C at 230 VAC

1.67 %/K above +55°C at 115 VAC

Switching frequency - multi output – Vout 1 5 VDC model: 70 kHz typ. (pulse frequency modulation)

(at 230 VAC) other models: 115 kHz typ. (pulse frequency modulation)

– Vout 2 750 kHz typ. (pulse frequency modulation)

– Vout 3 510 kHz typ. (pulse frequency modulation)

Isolation voltage – Input / Output (60 s) 4000 VAC

(2 x MOPP insulation) – Input / Case (60 s) 2500 VAC

Isolation resistance (at 500 VDC) 100 MOhm min.

– Electrostatic discharge ESD IEC / EN 61000-4-2, 8kV/6kV perf. criteria A

– RF field immunity IEC / EN 61000-4-3, 20V/m perf. criteria A

– Electrical fast transients/burst immunity IEC / EN 61000-4-4, ± 2kV perf. criteria A

– Surge IEC / EN 61000-4-5, ± 1kV/± 2kV perf. criteria A

– Conducted RF IEC / EN 61000-4-6, 20 Vrms perf. criteria A

– Magnetic field (only for single output models) IEC / EN 61000-4-8, 10A/m perf. criteria A

Voltage dip and interruptions according to EN 60601-1-2 30%, 500ms perf. criteria A

reference: 100 VAC / 50Hz 60%, 100ms perf. criteria B

> 95%, 10ms perf. criteria A

> 95%, 5000ms perf. criteria B

Environmental compliance – Reach www.tracopower.com/products/reach-declaration.pdf

– RoHS RoHS directive 2011/65/EU

Connection screw terminal
