Si39-501 Model Selection
General Information 7
Connectable Indoor Unit
Note:FXDQ has following 2 Series, as show below. General, Asia (except for EU, China and
Australia)
FXDQ-NVET: without Drain Pump
FXDQ-NVE: with Drain Pump
Connectable Indoor Unit (Connection Unit Series)
Note: BEV unit is required for each indoor unit.
Indoor unit capacity
Use the above tables to determine the capacities of indoor units to be connected. Make sure the
total capacity of indoor units connected to each outdoor unit is within the specified value (kW).
The total capacity of connected indoor units must be within a range of 50 to 130% of the
rated capacity of the outdoor unit.
In some models, it is not possible to connect the maximum number of connectable indoor
units. Select models so the total capacity of connected indoor units conforms to the
specification.
Type Model Name Power Supply
Ceiling Mounted
Cassette Type
(Double Flow)
FXCQ 20M 25M 32M 40M 50M 63M 80M — 125M — —
VE
Ceiling Mounted
Cassette Type
(Multi Flow)
FXFQ — 25M 32M 40M 50M 63M 80M 100M 125M — —
Ceiling Mounted
Cassette Corner Type
FXKQ —25M32M40M—63M—————
Slim Ceiling Mounted
Duct Type
FXDQ 20N25N32N40N50N63N—————
Ceiling Mounted
Built-In Type
FXSQ 20M 25M 32M 40M 50M 63M 80M 100M 125M — —
Ceiling Mounted
Duct Type
FXMQ — — — 40M 50M 63M 80M 100M 125M 200M 250M
Ceiling Suspended
Type
FXHQ — — 32M — — 63M — 100M — — —
Wall Mounted Type
FXAQ 20M25M32M40M50M63M—————
Floor Standing Type
FXLQ 20M25M32M40M50M63M—————
Concealed Floor
Standing Type
FXNQ 20M25M32M40M50M63M————— V1
Type Model Name Power Supply
Ceiling Suspended
Cassette Type
FXUQ ——————71M100M 125M — —
V1Wall Mounted Type
FXAQ-MH
20MH 25MH 32MH 40MH 50MH
——————
Floor Standing Type
FXLQ-MH
20MH 25MH 32MH 40MH 50MH
——————
Connection Unit BEVQ-M 50M 50M 50M 50M 50M — 71M 100M 125M — — VE
New refrigerant model code P20
type
P25
type
P32
type
P40
type
P50
type
P63
type
P80
type
P100
type
P125
type
P200
type
P250
type
Selecting model capacity 2.2
kW
2.8
kW
3.5
kW
4.5
kW
5.6
kW
7.0
kW
9.0
kW
11.2
kW
14.0
kW
22.4
kW
28.0
kW
Equivalent output 0.8HP 1HP
1.25HP
1.6HP 2.0HP 2.5HP 3.2HP 4HP 5HP 8HP 10HP
