Si39-501 Specifications
Specifications 13
Notes:
1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level
difference : 0m.
2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level
difference : 0m.
Model Name (Combination Unit) RXQ18MAY1 RXQ20MAY1
Model Name (Independent Unit) RXQ8MAY1+RXQ10MAY1 RXQ10MAY1+RXQ10MAY1
1 Cooling Capacity (19.5°CWB)
kcal / h 43,600 48,400
Btu / h 173,000 192,000
kW 50.7 56.3
2 Cooling Capacity (19.0°CWB) kW 50.4 56.0
Casing Color Ivory White (5Y7.5/1) Ivory White (5Y7.5/1)
Dimensions: (H×W×D) mm (1600×930×765)+(1600×930×765) (1600×930×765)+(1600×930×765)
Heat Exchanger Cross Fin Coil Cross Fin Coil
Comp.
Type Hermetically Sealed Scroll Type Hermetically Sealed Scroll Type
Piston Displacement m³/h (13.72+10.53)×2 (13.72+10.53)×2
Number of Revolutions r.p.m (6480, 2900)×2 (6480, 2900)×2
Motor Output×Number
of Units
kW (0.7+4.5)+(1.6+4.5) (1.6+4.5)×2
Starting Method Direct on line (Inverter Drive) Direct on line (Inverter Drive)
Fan
Type Propeller Fan Propeller Fan
Motor Output kW 0.75×2 0.75×2
Air Flow Rate m³/min 175+180 180+180
Drive Direct Drive Direct Drive
Connecting
Pipes
Liquid Pipe mm
φ
12.7 (Brazing Connection)
φ
15.9 (Brazing Connection)
Gas Pipe mm
φ
28.6 (Brazing Connection)
φ
28.6 (Brazing Connection)
Product Mass (Machine Weight) kg 230+230 230+230
Safety Devices
High Pressure Switch, Fan Driver Overload Protector, Over
Current Relay, Inverter Overload Protector,
Fusible Plugs
High Pressure Switch, Fan Driver Overload Protector, Over
Current Relay, Inverter Overload Protector,
Fusible Plugs
Capacity Control % 7~100 7~100
Refrigerant
Refrigerant Name R-410A R-410A
Charge kg 7.6+8.6 8.6+8.6
Control Electronic Expansion Valve Electronic Expansion Valve
Refrigerator Oil Refer to the nameplate of compressor Refer to the nameplate of compressor
Standard Accessories
Installation Manual, Operation Manual, Connection Pipes,
Clamps
Installation Manual, Operation Manual, Connection Pipes,
Clamps
Drawing No. C: 4D049339, 4D049340 C: 4D049340
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3412
cfm=m³/min×35.3
