3 Nomenclature

3-1 Indoor units

V1M40S Q BFX

Power supply symbol

V1: 1~, 230V, 50Hz

VE: 1~, 220-240V, 50Hz

Special series for Europe (CE approved)*

M: Indicates major design category

M7: Indicates DENV production

Capacity Indication

Conversion to horsepower:

Indicates use with ozone friendly refrigerant R-410A

20: 0.8HP

25: 1HP

32: 1.25HP

40: 1.6HP

50: 2.0HP

63: 2.5HP

80: 3.2HP

100: 4HP

125: 5HP

200: 8HP

250: 10HP

Model name

Z: 4-way blow ceiling mounted cassette (600x600mm)

F: 4-way blow ceiling mounted cassette

C: 2-way blow ceiling mounted cassette

K: Ceiling mounted corner cassette

S: Concealed ceiling unit

D: Concealed ceiling unit (small)

M: Concealed ceiling unit (large)

H: Ceiling suspended unit

A: Wall mounted unit

L: Floor standing unit

LM: Concealed floor standing unit

Indicates that this is an INVERTER HEAT PUMP/COOLING ONLY

or a HEAT RECOVERY indoor unit
