Biostar X470GTN Версия 5.x [16/83] Panel1 front panel header

16 | Chapter 2: Hardware installaon

PANEL1: Front Panel Header

This connector includes Power-on, Reset, HDD LED and Power LED connecons. It allows user

to connect the PC case’s front panel switch funcons.

Pin Assignment Funcon Pin Assignment Funcon

1 N/A N/A 2 Power LED (+)

Power

LED

3 HDD LED(+)

HDD

LED

4 Power LED (+)

5 HDD LED(-) 6 Power LED (-)

7 Ground

Reset

Buon

8 Power Buon

Power-On

Buon

9 Reset Control 10 Ground

SPKR1: Chassis Speaker Header

Please connect the chassis speaker to this header.

Pin Assignment

1 +5V

2 N/A

3 N/A

4 Speaker

SATA1~SATA4: Serial ATA 6.0 Gb/s Connectors

These connectors connect to SATA hard disk drives via SATA cables.

Pin Assignment

1 Ground

2 TX+

3 TX-

4 Ground

5 RX-

6 RX+

7 Ground
