4 | Chapter 1: Introducon
1�3 Specifications
Specicaons
CPU Support
Socket AM4 supports AMD A-series APU / Ryzen CPU / NPU for Socket AM4
Maximum CPU TDP (Thermal Design Power): 105Wa
* Please refer to www.biostar.com.tw for CPU support list.
Chipset AMD X470
Memory
Supports Dual Channel DDR4 1866/ 2133/ 2400/ 2667/ 2933(OC)/ 3200(OC)
2 x DDR4 DIMM Memory Slot, Max. Supports up to 32 GB Memory
Each DIMM supports non-ECC and ECC Un-buered 8/16 GB DDR4 module
* DDR4 - 2667 only for Ryzen CPU.
* Please refer to www.biostar.com.tw for Memory support list.
Storage
4x SATA III Connector (6Gb/s) : Supports AHCI & RAID 0, 1, 10
1x M.2 (32Gb/s) : Supports PCI-E & SATA SSD
* M.2 (32Gb/s) : The bandwidth is depended on CPU, Ryzen is 32Gb/s ; APU & NPU is 16Gb/s.
LAN
Realtek RTL 8118AS
10/ 100/ 1000 Mb/s auto negoaon, Half / Full duplex capability
Audio Codec
ALC892
7.1 Channels, High Denion Audio, Hi-Fi(Front)
USB
1x USB 3.1 Gen2 (10Gb/s) Type-C port (1 on rear I/O)
1x USB 3.1 Gen2 (10Gb/s) Type-A port (1 on rear I/O)
6x USB 3.1 Gen1 (5Gb/s) port (4 on rear I/Os and 2 via internal header)
2x USB 2.0 port (2 via internal header)
Expansion Slots 1x PCIe 3.0 x16 Slot (When using APU or NPU, the bandwidth is x8 speed)
Rear I/Os
1x PS/2 Mouse/ Keyboard Port
1x DVI-D Port
1x HDMI Port
1x LAN port
1x USB 3.1 Gen2 (10Gb/s) Type-C Port
1x USB 3.1 Gen2 (10Gb/s) Type-A Port
4x USB 3.1 Gen1 (5Gb/s) Port
5x Audio Jack
1x SPDIF_Out
Internal I/Os
4x SATA III 6.0Gb/s Connector
1x USB 2.0 Header (each header supports 2 USB 2.0 ports)
1x USB 3.1 Gen1 (5Gb/s) Header (each header supports 2 USB 3.1 Gen1 ports)
1x 4-Pin Power Connector
1x 24-Pin Power Connector
1x CPU Fan Connector
1x System Fan Connector
1x Front Panel Header
1x Front Audio Header
1x Clear CMOS Header
2x 5050 LED Header
Form Factor Mini-ITX Form Factor, 170 mm x 170 mm
OS Support
Windows 7(64bit) / 10(64bit)
