Biostar Hi-Fi B250S1 Версия 6.x [4/64] 3 specifications
![Biostar Hi-Fi B250S1 Версия 6.x [4/64] 3 specifications](/views2/1707945/page4/bg4.png)
4 | Chapter 1: Introducon
1�3 Specifications
Specicaons
CPU Support
Socket 1151 for Intel® Core i7 / i5 / i3 / Penum / Celeron processor
Maximum CPU TDP (Thermal Design Power): 95Wa
*
Please refer to www.biostar.com.tw for CPU support list.
Chipset INTEL® B250
Memory
Supports Dual Channel DDR4 1866/2133/2400
2x DDR4 DIMM Memory Slot, Max. Supports up to 32 GB Memory
Each DIMM supports non-ECC 4/8/16GB DDR4 module
*
DDR4-2400 for 7th Generaon Intel® Core™ Processor Family.
*
Please refer to www.biostar.com.tw for Memory support list.
Storage 4x SATA III (6Gb/s) : Supports AHCI
LAN
RTL8111H
10/ 100/ 1000 Mb/s auto negoaon, Half / Full duplex capability
Audio Codec
ALC887
7.1 Channels, High Denion Audio, Hi-Fi(Rear)
USB
INTEL® B250:
6x USB 3.0 port (4 on rear I/Os and 2 via internal headers)
6x USB 2.0 port (2 on rear I/Os and 4 via internal headers)
Expansion Slots
2x PCIe 3.0 x1 Slot
1x PCIe 3.0 x16 Slot
Rear I/Os
1x PS/2 Mouse
1x PS/2 Keyboard
1x DVI-D Port
4x USB 3.0 Port
2x USB 2.0 Port (only 5V power for charger)
2x USB 2.0 Port
1x LAN port
3x Audio Jack
Internal I/Os
4x SATA III Connector (6Gb/s)
2x USB 2.0 Header (each header supports 2 USB 2.0 ports)
1x USB 3.0 Header (each header supports 2 USB 3.0 ports)
1x 8-Pin Power Connector
1x 24-Pin Power Connector
1x 15-Pin SATA Power Connector (for USB power enhancement)
1x CPU Fan Connector
1x System Fan Connector
1x Front Panel Header
1x Front Audio Header
1x COM Serial Header
1x Clear CMOS Header
Form Factor uATX Form Factor, 226 mm x 187 mm
OS Support
Windows 7 (32/64bit) / 8.1(64bit) /10(64bit)
*
Windows 7 (32/64bit) / 8.1(64bit) for 6th Generaon Intel® Core™ Processor Family only.
*
Biostar reserves the right to add or remove support for any OS with or without noce.
