Adaptors for Connection of Air Conditioners SiE30-408
204 Appendix
4 To operate the system on two input contacts using instantaneous input for the input
A and input B
(Use instantaneous input with ON time of 200 msec or more for the input A.)
Cautions Using normal input for the input B in Positions 7 to A will put the system into forcedly stop
function (with input A disregarded).
In Position B, the normal input cannot be used for the input B.
3. Input of temperature settings
Temperature settings corresponding to resistance values in the range of 0 to 135Ω can be
made.
Caution The resistance values are counted in wiring resistance.
Position Function Contents of input A Contents of input B
7
Remote controller
inhibited
Operation (The remote controller is
inhibited at all times.)
Stop + Remote
controller inhibited
8 Centralized priority
Operation + Remote controller
permitted
9
Remote controller stop
permitted
Operation + Only remote controller stop
permitted
(Operation from remote controller is
impossible.)
A
Remote controller
permitted / stop
Only remote controller permitted
(Operation from remote control is
impossible.)
B Last pressing priority
Operation (The remote controller is
permitted at all times.)
Stop (The remote
controller is permitted
at all timed.)
In order to make temperature settings from both remote and remote
controllers, set thisswitch to "Permitted". (Factory set: Permitted)
Permitted: Use this mode to make temperature settings from both remote
and remote controllers. (Last setting priority control is enabled.)
Inhibited: Use this mode only to make temperature settings from the
remote. (No temperature settingsare enabled from the remote
controller.)
NEVER apply voltage to terminal
A
+
or A
-
.
Adaptor
KRP4A51 • 52 • 53
SS2
IMPOSSIBLE POSSIBLE
Set temp. (°C) 16 17 18 19 20 21 22 23 24
Resistance value
(Ω)
0.0~3.4
5.0~
11.6
13.8~
20.0
22.4~
28.4
31.0~
36.4
39.4~
44.8
48.2~
52.8
56.6~
61.2
65.2~
69.4
Set temp. (°C) 25 26 27 28 29 30 31 32
Resistance value
(Ω)
73.8~
77.8
82.4~
85.8
91.0~
94.0
99.4~
102.2
108.6~
110.4
117.2~
119.2
125.8~
127.4
134.2~
140.0
(Wiring specifications)
Types of wires ... Sheathed vinyl cords
Size of wire ... 1.25 to 2.00 mm
2
Total length of wiring ... 70 m at maximum
(Caution)
In order to prevent malfunctions, isolate this wiring from the power lines.
