VLAN ID VLAN Define Major Member
VLAN 1 Public VLAN WSW-2401A_220
WSW-2401A_ 10
WSW-2401A _20
WSW-2401a _30
Server
Network_Printer_1
Network_Printer_2
VLAN 2 Clinets connect to [192.168.0.10]
VLAN 3 Clinets connect to [192.168.0.20]
VLAN 4 Clinets connect to [192.168.0.30]
WGSW-2840_192.168.0.222 Core-Switch VLAN Configuration
192.168.0.222 VLAN Configuration
Port Link Type PVID Egress Link Partner
Port1 Always Untag 1 Untag=1,2,3,4 Server
Port5 Trunk 1 Tag=1,2,3,4 192.168.0.30
Port6 Trunk 1 Tag=1,2,3,4 192.168.0.20
Port7 Trunk 1 Tag=1,2,3,4 192.168.0.10
WGSW-2840_192.168.0.10 Edge-Switch VLAN Configuration
192.168.0.10 VLAN Configuration
Port Link Type PVID Egress Link Partner
Port1 Always Untag 2 Untag=1,2 PC
Port2 Always Untag 2 Untag=1,2 PC
Port3 Always Untag 2 Untag=1,2 PC
Port18 Always Untag 1 Untag=1,2,3,4 NtworkPrinter
Port28 Trunk 1 Tag=1,2,3,4 Core-2840
WGSW-2840_192.168.0.20 Edge-Switch VLAN Configuration
192.168.0.20 VLAN Configuration
Port Link Type PVID Egress Link Partner
Port1 Always Untag 3 Untag=1,3 PC
