Port2 Always Untag 3 Untag=1,3 PC
Port3 Always Untag 1 Untag=1,2,3,4 NtworkPrinter
Port28 Trunk 1 Tag=1,2,3,4 Core-2840
WGSW-2840_192.168.0.30 Edge-Switch VLAN Configuration
192.168.0.30 VLAN Configuration
Port Link Type PVID Egress Link Partner
Port1 Always Untag 4 Untag=1,4 PC
Port2 Always Untag 4 Untag=1,4 PC
Port3 Always Untag 4 Untag=1,4 PC
Port28 Trunk 1 Tag=1,2,3,4 Core-2840
