SiE30-408 Recording and Playback of Operation Data
Service Checker Type3 Application Edition 145
Cursor
Graph manipulations
Display of operation data
Buttons Contents
Enlargement (F1) Used to display the graph for a period of time shortened.
Reduction (F2) Used to display the graph for a period of time prolonged.
Backward (F3) Used to move the graph to the left on the window.
Forward (F4) Used to move the graph to the right on the window.
Left (F5) Used to move a cursor on the graph to the left.
Right (F6) Used to move a cursor on the graph to the right.
