http://www.tracopower.com Rev: 1.8 / 1018
Safety Instructions:
Before installation read these instructions carefully and
completely. This installation instruction cannot account for
every possible condition of installation, operation or
maintenance. Further information can be obtained from
your local distributor’s office or from the product datasheet,
which can be our website:
http://www.tracopower.com.
Before any installation, maintenance or modification work
ensure that the main switch is switched off and prevented
from being switched on again. Non-observance, touching
of any live components or improper handling of this power
supply can result in death, severe personal injury or
substantial property damage. Proper and safe operation is
dependent on proper storage, handling, installation and
operation.
While applying connections, no mechanical stress should
be applied to the printed circuit board and its surface
mounted components.
Compliance with the relevant national regulations must be
ensured. Before operation is started the following condi-
tions must be ensured:
Connection to mains supply in compliance with national
regulations.
Power supply and mains cables must be sufficiently
fused.
All output wires must be rated for the power supply
output current and must be connected with the correct
polarity.
Do not disconnect while circuit is alive.
Never work on the power supply if power is supplied:
Risk of electric arcs and electrical shock, which can cause
death, severe personal injury or substantial property
damage.
Warning: Hazardous voltages and components storing a
very substantial amount of energy are present in this
power supply during normal operating conditions. Improper
handling may result in an electric shock or serious burns!
Do not open the power supply
Do not introduce any objects into the power supply. An
output voltage adjustment potentiometer (if existing)
may only be actuated using an insulated screwdriver.
Keep away from fire, water and chemicals.
Installation Instructions
This power supply is designed for professional indoor
systems. In operation the power supply must not be
accessible. It may be installed and put into service by
qualified personnel only.
All required connections have to be carried out as
described in the table on the front side.
By use of stranded wires, all strands must be fastened in
the terminal blocks (potential danger of short circuits).
Do not cover any ventilation holes. Optimal cooling
performance must be ensured. Observe power derating
(see datasheet).
For Class II operation, the ground terminal is not allowed
to be connected & the unit must not be mounted through 4
holes to any kind of conductive surface
The internal fuse(s) may not be replaced by the user. If an
internal fuse has blown, the power supply has most
properly an internal defect and, for safety reasons, must be
shipped to the local distributor.
To comply with EN 55022 Class B, Field Ground (FG) must
be connected, by fixing the unit to the chassis using metal
pillars, at all four mounting points.
Recycling: The unit contains elements that are suitable for
recycling, and components that need special disposal. You
are therefore requested to make sure that the power
supply will be recycled environment friendly at the end of
its service life.
