Hi-Fi K1-I
17
F_AUDIO1: Front Panel Audio Header
This header allows user to connect the chassis-mount front panel audio I/O which
supports HD audio standard.
Pin Assignment
1 MIC1_L
2 GND_AUD
3 NA
4 FP_AUD_DETECT
5 LINEOUT_R_F
6 JD_MIC_F
7 GND_AUD
8 Key
9 LINEOUT_L_F
10 FP_HPD
Note: This header does not support AC'97 audio.
