Motherboard Manual
2
1.3 Motherboard Specifications
Specifications
CPU Support
Socket 1150 for Intel® Core i7 / i5 / i3 / Pentium / Celeron processor
Maximum CPU TDP (Thermal Design Power): 95Watt
* Please refer to
www.biostar.com.tw for CPU support list.
Chipset INTEL® H81
Memory
Supports Dual Channel DDR3 1066/ 1333/ 1600
2 x DDR3 DIMM Memory Slot, Max. Supports up to 16 GB Memory
Each DIMM supports non-ECC 512MB/ 1/ 2/ 4/ 8 GB DDR3 module
* Please refer to
www.biostar.com.tw for Memory support list.
Storage
INTEL® H81, Supports AHCI
2x SATA 6Gb/s Connector
2x SATA 3Gb/s Connector
LAN
RTL8111G
10 / 100/ 1000 Mb/s auto negotiation Half / Full duplex capability
Audio Codec CM108AH, 2 Channels, High Definition Audio, Biostar Hi-Fi
USB
2x USB 3.0 port (2 via internal headers)
6x USB 2.0 port (4 on rear I/Os and 2 via internal headers)
Expansion Slots
1x PCIe 2.0 x1 Slot
1x PCIe 2.0 x16 Slot (x16)
Rear I/Os
1x PS/2 Mouse
1x PS/2 Keyboard
1x VGA Port
1x HDMI Port
1x LAN port
4x USB 2.0 Port
3x Audio Jack
Internal I/Os
2x SATA 6.0Gb/s Connector
2x SATA 3.0Gb/s Connector
1x USB 3.0 Header (each header supports 2 USB 3.0 ports)
1x USB 2.0 Header (each header supports 2 USB 2.0 ports)
1x 4-Pin Power Connector
1x 24-Pin Power Connector
1x CPU Fan Connector
1x System Fan Connector
1x Front Panel Header
1x Front Audio Header
1x Clear CMOS Header
1x Serial Port Header
Form Factor ATX Form Factor, 230 mm x 174 mm
OS Support
Windows 7/ 8/ 8.1
