TRACO POWER TPI65-115A-JP Datasheet онлайн
AC/DC Power Supply
TPI 65A-J Series, 65 Watt
•
65 Watt open frame power supplies in a
3" x 2" package
•
Compact and cost efficient design
•
Peak power function up to 140%
•
I/O reinforced isolation 3000 VAC
•
Operating temperature range –40°C to
+85°C
•
No load input power <0.3W (acc. ErP
directive)
•
High efficiency up to 93%
•
Internal EN 55032 class B filter
•
Protection class II prepared
•
3 year product warranty
The TPI 65A-J is a 65 Watt AC/DC open frame power supplies series with a
3000 VAC reinforced isolation system. Our TPI line specifically focuses on pro-
viding cost efficient industrial power supplies in compact designs. This series
offers a peak power function which enables the unit to deliver up to 140% of
the rated power for up to 10 seconds. Excellent efficiency of up to 93% allows
a compact design and an operating temperature range (natural convection) of
–40°C to +60°C without derating, while going up to +85°C with either load
derating or forced cooling. They are designed to meet the ErP directive (< 0.3
W no load power consumption) and come with an EMC characteristics dedicat-
ed for applications in industrial/automation and test & measurement fields.
High reliability is provided by use of industrial high-quality grade components
and an excellent thermal management. It makes the TPI 65A-J an ideal solution
for any demanding industrial devices or space critical applications.
Models
Order Code
Output Power
max.
Output Voltage
nom. (adjustable)
Output Current
max.
Output Current
peak
Efficiency
typ.
TPI 65-105A-JP
50 W
5 VDC (4.0 - 5.5 VDC)
10'000 mA
13'000 mA
90 %
TPI 65-112A-JP
65 W
12 VDC (9.6 - 13.2 VDC)
5'420 mA
7'500 mA
93 %
TPI 65-115A-JP
15 VDC (12.0 - 16.5 VDC)
4'340 mA
6'000 mA
94 %
TPI 65-124A-JP
24 VDC (19.2 - 26.4 VDC)
2'710 mA
3'750 mA
94 %
TPI 65-136A-JP
36 VDC (28.8 - 39.6 VDC)
1'810 mA
2'500 mA
93 %
TPI 65-148A-JP
48 VDC (38.4 - 52.8 VDC)
1'360 mA
1'875 mA
93 %
TPI 65-153A-JP
53 VDC (42.4 - 58.3 VDC)
1'240 mA
1'698 mA
93 %
www.tracopower.com
July 31, 2020
Page 1 / 4
