Input Voltage
- AC Range
85 - 264 VAC (Full Range)
- DC Range
120 - 370 VDC (Designed for, no certification)
Input Frequency
47 - 63 Hz
Input Current
- Full Load & Vin = 230 VAC
900 mA max.
- Full Load & Vin = 115 VAC
1'600 mA max.
Power Consumption
- At no load
180 mW max.
- At no load
110 mW typ.
Input Inrush Current
- At 230 VAC
75 A max.
- At 115 VAC
40 A max.
Input Protection
T 3.15 A / 250 VAC (Internal Fuse in L)
Recommended Input Fuse
(The need of an external fuse has to be assessed
in the final application.)
Input Specifications
Output Voltage Adjustment
–20% to +10% (53 VDC models)
±10% (other models)
(By trim potentiometer)
Output power must not exceed rated power!
Voltage Set Accuracy
±1% max.
Regulation
- Input Variation (Vmin - Vmax)
0.2% max.
- Load Variation (0 - 100%)
0.7% max. (5 VDC model)
0.5% max. (other output models)
Output Current peak
max. peak duration: 5 s with 20% duty cycle
and 70% average operation power
Ripple and Noise
(20 MHz Bandwidth)
5 VDC model:
75 mVp-p typ. (w/ 10 µF, 25 V, MLCC)
12 VDC model:
75 mVp-p typ. (w/ 10 µF, 25 V, MLCC)
15 VDC model:
75 mVp-p typ. (w/ 10 µF, 25 V, MLCC)
24 VDC model:
75 mVp-p typ. (w/ 1 µF,50 V, MLCC)
36 VDC model:
75 mVp-p typ. (w/ 1 µF,50 V, MLCC)
48 VDC model:
150 mVp-p typ. (w/ 0.1 µF,100 V, MLCC)
53 VDC model:
150 mVp-p typ. (w/ 0.1 µF,100 V, MLCC)
Capacitive Load
5 VDC model:
20'000 µF max.
12 VDC model:
4'520 µF max.
15 VDC model:
2'900 µF max.
24 VDC model:
1'130 µF max.
36 VDC model:
520 µF max.
48 VDC model:
285 µF max.
53 VDC model:
235 µF max.
Minimum Load
Not required
Temperature Coefficient
±0.02 %/K max.
Hold-up Time
- At 230 VAC
90 ms min.
- At 115 VAC
15 ms min.
Start-up Time
- At 230 VAC
800 ms max.
- At 115 VAC
950 ms max.
Short Circuit Protection
Continuous, Automatic recovery
Output Current Limitation
165% typ. of Iout max.
Overvoltage Protection
125 - 140% of Vout nom.
Transient Response
- Response Deviation
3% max. (50% to 75% Load Step at 2.5 A/µs)
- Response Time
600 µs typ. (50% to 75% Load Step at 2.5 A/µs)
Output Specifications
TPI 65A-J Series, 65 Watt
All specifications valid at nominal voltage, full load and +25°C after warm-up time unless otherwise stated.
www.tracopower.com
July 31, 2020
Page 2 / 4
