Safety Standards
- IT / Multimedia Equipment
EN 62368-1
IEC 62368-1
UL 62368-1
- Certification Documents
www.tracopower.com/overview/tpi65a-j
Protection Class
Class I (Prepared): Connection to PE
Class II (Prepared): Reinforced Insulation
Safety Specifications
EMI Emissions
- Conducted Emissions
EN 55011 class B (internal filter)
EN 55032 class B (internal filter)
FCC Part 15 class B (internal filter)
- Radiated Emissions
EN 55011 class B (internal filter)
EN 55032 class B (internal filter)
FCC Part 15 class B (internal filter)
- Harmonic Current Emissions
EN 61000-3-2, class A
- Voltage Fluctuations & Flicker
EN 61000-3-3
EMS Immunity
EN 55024 (IT Equipment)
- Electrostatic Discharge
Air:
EN 61000-4-2, ±15 kV, perf. criteria A
Contact:
EN 61000-4-2, ±6 kV, perf. criteria A
- RF Electromagnetic Field
EN 61000-4-3, 20 V/m, perf. criteria A
- EFT (Burst) / Surge
EN 61000-4-4, ±4 kV, perf. criteria A
L to L:
EN 61000-4-5, ±2 kV, perf. criteria A
L to PE:
EN 61000-4-5, ±4 kV, perf. criteria A
- Conducted RF Disturbances
EN 61000-4-6, 20 Vrms, perf. criteria A
- PF Magnetic Field
Continuous:
EN 61000-4-8, 100 A/m, perf. criteria A
- Voltage Dips & Interruptions
230 VAC / 50 Hz:
EN 61000-4-11
115 VAC / 60 Hz:
EN 61000-4-11
EMC Specifications
Relative Humidity
95% max. (non condensing)
Temperature Ranges
- Operating Temperature
–40°C to +85°C
- Storage Temperature
–40°C to +85°C
Power Derating
- High Temperature
See application note:
www.tracopower.com/overview/tpi65a-j
- Low Input Voltage
4 %/V below 85 VAC
Cooling System
Natural convection (20 LFM)
Altitude During Operation
5'000 m max.
Switching Frequency
60 kHz typ. (5 VDC models)
120 kHz typ. (other models)
Insulation System
Reinforced Insulation
Isolation Test Voltage
- Input to Output, 60 s
3'000 VAC
Isolation Resistance
- Input to Output, 500 VDC
100 MΩ min.
Leakage Current
(at 264 VAC)
- Earth Leakage Current
75 µA max.
Reliability
- Calculated MTBF
1'490'000 h (MIL-HDBK-217F, ground benign)
Environment
- Vibration
IEC 60068-2-6
- Mechanical Shock
IEC 60068-2-27
Connection Type
JST
Weight
117 g
Environmental Compliance
- Reach
www.tracopower.com/info/reach-declaration.pdf
- RoHS
www.tracopower.com/info/rohs-declaration.pdf
General Specifications
Supporting Documents
Overview Link (for additional Documents)
www.tracopower.com/overview/tpi65a-j
TPI 65A-J Series, 65 Watt
All specifications valid at nominal voltage, full load and +25°C after warm-up time unless otherwise stated.
www.tracopower.com
July 31, 2020
Page 3 / 4
