TPP 450A Series, 450 Watt
www.tracopower.com Page 2 of 5
All specifications valid at nominal input voltage, full load and +25°C after warm-up time unless otherwise stated.
Input Specifications
Input voltage range – AC range (universal input) 85 – 264 VAC (47 – 63 Hz)
– DC range 120 – 370 VDC
– Power derating at low input voltage 1.33 %/V below 100 VAC
Input current at full load – at 100 VAC 5.8 A max.
– at 240 VAC 2.4 A max.
Input protection – Internal fuse in line and neutral T 6.3 A / 250 VAC
Zero load power consumption (acc. ErP directive) 12 Vout models: 0.3 W typ.
other output models: 0.5 W typ.
Leakage current – at 264 VAC 100 µA max.
Power factor 0.95 min. (active power correction)
Output Specifications
Voltage set accuracy – at 230 VAC ± 1%
Output voltage adjustment ± 8%
Regulation – Input variation (85 - 264 VAC) 0.2% max.
– Load variation (0 - 100%) 0.5% max.
Minimum load not required
Temperature coefficient 0.02 %/K max.
Hold-up time – at 115 VAC 14 ms typ.
Start-up time 2 s max.
Rise time 30 ms typ.
Ripple and noise 12 VDC model: 250 mVp-p typ.
(w. cap. 1µF/25V 1206 X7R MLCC)
(20 MHz Bandwidth) 15 VDC model: 300 mVp-p typ.
(w. cap. 1µF/25V 1206 X7R MLCC)
24 VDC model: 240 mVp-p typ.
(
w. cap. 1µF/50V 1206 X7R MLCC)
36 VDC model: 360 mVp-p typ.
(w. cap. 1µF/50V 1206 X7R MLCC)
48 VDC model: 480 mVp-p typ.
(w. cap. 1µF/50V 1206 X7R MLCC)
Transiente response – Peak deviation (50 - 75% load change) 3% Vout typ.
– Recovery time 600 µs typ.
Overvoltage protection 110 – 135% of Vout (latch mode)
(Featured by main power output)
Overload protection 115 – 150% of Iout max. (current limitation)
(Featured by main power output and standby power output)
Short circuit protection – Protection level 1 (nominal) continuous, automatic recovery (hiccup mode)
(Featured by all outputs) – Protection level 2 (instantaneous high current) latch
Auxiliary outputs – Power source for fan (variable fan speed control) 12 VDC / 500 mA max.
Refers to pin +Fan and –Fan
– Standby power source 5 VDC / 2000 mA max.
Refers to pin +Standby and –Standby
Capacitive load 12 Vout model: 31‘250 µF max.
15 Vout model: 20‘000 µF max.
24 Vout model: 7'820 µF max.
36 Vout model: 3'500 µF max.
48 Vout model: 1'960 µF max.
