TPP 450A Series, 450 Watt

www.tracopower.com

Page 5 of 5

Rev. August 6, 2018

Optional cable for auxilary output connection

9 4

8 3

7 2

6 1

500 mm (typ.)

Auxilary cables

Pin AUX2 AUX1 Color AWG

1 +Fan No Wire yellow 26

2 +Sense gray 26

3 +Remote orange 26

4 PG blue 26

5 +Standby red 22

6 –Fan No Wire brown 26

7 –Sense green 26

8 –Remote brown 26

9 No Wire --- ---

10 –Standby black 22

Order code Connection

TPP 450-AUX2

2 x 5 pin

TPP 450-AUX1

2 x 4 pin
