Planet FSD-2405 [4/18] Product features
![Planet FSD-2405 [4/18] Product features](/views2/1070864/page4/bg4.png)
2
1.3 Product Features
。 Complies with IEEE 802.3, 10Base-T, and IEEE 802.3u 100Base-TX
。 16/24-Port 10/100Mbps TX Auto-Negotiation Ethernet Switch
。 Features Store-and-Forward mode with wire-speed filtering and forward-
ing rates
。 IEEE 802.3x flow control for full duplex operation and Backpressure for
half duplex operation
。 Support 8K absolute MAC addresses
。 Supports to handle up to 1552 bytes packet
。 Automatic address learning and address aging
。 Supports Auto MDI/MDI-X function
。 Full/Half-Duplex capability on each TX port
。 LED indicators for simple diagnostics and management
。 Desktop-Si�e and easy installation anywhere Desktop-Size and easy installation anywhere
。 Rack-mountable design Rack-mountable design
。 FCC, CE class A compliant
