Planet FSD-2405 [5/18] Model fsd 1605 fsd 2405

  

Model FSD-1605 FSD-2405



10/100Base-TX Ports 16 RJ-45 MDI/MDI-X 24 RJ-45 MDI/MDI-X

Dimensions (W x H x D) 280 x 170 x 44 mm

Weight (KG) 1.60 KG

Power Consumption 13.6 watts / 46.4BTUwatts / 46.4BTU / 46.4BTUBTU

Power Requirement 100~240 AC, 50-60 H� AC, 50-60 H�AC, 50-60 H�



Switch Architecture Store-and-ForwardForwardorward

Address Table 8K entries, auto learning/ageing

Shared Data Buffer 1.25Mbits

Switch Fabric 3.2 Gbps 4.8 Gbps

Switch Throughput 2.38 Mpps 3.57 Mpps

Flow Control IEEE 802.3x full duplex operating and ow control

Packet Control Runt & CRC ltering

Standard Conformance

Network Standards

IEEE 802.3 (Ethernet)

IEEE 802.3u (Fast Ethernet)

IEEE 802.3x (Flow control) 802.3x (Flow control)802.3x (Flow control)

Operation Temperature

0~50ºC

Storage Temperature

-20~70ºC

Operation Humidity 10% to 90% (Non-condensing)

Storage Humidity 5% to 90% (Non-condensing)

Regulation Compliance FCC Part 15 Class A, CE
