2.1.4 FGSW-2620 Rear Panel

The rear panel of the Switch indicates an AC inlet power socket, which

accepts input power from 100 to 240VAC, 50-60Hz. Figure 2-2 shows

Rear panel of the Switch.

Figure 2-2 Rear Panel of FGSW-2620

Power Notice:

1. The device is a power-required device, it means, it will not work till it

is powered. If your networks should active all the time, please con-

sider using UPS (Uninterrupted Power Supply) for your device. It will

prevent you from network data loss or network downtime.

2. In some area, installing a surge suppression device may also help

to protect your Switch from being damaged by unregulated surge or

current to the Switch or the power adapter.

2.2 Installing a FGSW-2620

This part describes how to install your Ethernet Switch and make

connections to the Switch. Please read the following topics and perform

the procedures in the order being presented.

To install your Switch on a desktop or shelf, simply complete the

following steps.

2.2.1 Desktop Installation

To install a Switch on a desktop or shelf, simply complete the following

steps:

Step1: Attach the rubber feet to the recessed areas on the bottom

of the Switch.

Step2: Place the Switch on a desktop or shelf near an AC power

source.
