Chapter 2: Hardware Installaon | 11

TB250-BTC D+

SYS_FAN6/ SYS_FAN7: System Fan Header (Without monitoring)

Pin Assignment

1 Ground

2 +12V

3 NA

4 Fan Control

Note

 CPU_FAN1,SYS_FAN1/2/3/4/5/6/7support4-pinand3-pinheadconnectors.Whenconnecng

withwiresontoconnectors,pleasenotethattheredwireistheposiveandshouldbeconnectedto

pin#2,andtheblackwireisGroundandshouldbeconnectedtopin#1(GND).

2.4 Install System Memory

DDR4 Modules
