7. Product Specifications

Product GSD-503 GSD-504 GSD-803 GSD-804

Hardware Specification

10/100/1000Base-T Ports 5 Auto MDI/MDIX ports 8 Auto MDI/MDIX ports

Dimensions (mm)

155 x 86 x 26 176 x 106 x 30 155 x 86 x 26 176 x 106 x 30

Weight (kg)

0.36 0.16 0.39 0.21

Power Requirement

External power adapter 12V 1A

Power Consumption /

Dissipation

5.4 watts / 18 BTU 8.1 watts / 27 BTU

Switch Specification

Switch Processing Scheme Store-and-Forward

Address Table 4K entries

Flow Control

Back pressure for half duplex, IEEE 802.3x Pause Frame for full

duplex

Switch fabric 10Gbps 16Gbps

Throughput (packet per

second)

7.44Mpps 11.9Mpps

Jumbo packet size 9K

Standards Conformance

Standards Compliance

IEEE 802.3 (Ethernet)

IEEE 802.3u (Fast Ethernet)

IEEE 802.3ab(Gigabit Ethernet)

IEEE 802.3x (Full-duplex flow control)

Temperature

Operating: 0~50 degree C

Storage: -40~70 degree C

Humidity Operating

Operating: 5% to 90%, Storage: 5% to 90% (Non-condensing)

Regulation Compliance FCC Part 15 Class A, CE
