www.tracopower.com Page 2 of 6

Industrial Power Supplies

TCL Series 24 to 240 Watt

Input Specifications

Input voltage range 85–264 VAC/85–375 VDC

TCL 240 model: 85–132/187–264 VAC autoselect (no DC input)

Output derating – at operation between 85...93 VAC/85...130 VDC 15% for TCL 060 & TCL 120

20% for TCL 024-112 & TCL 024-124 & TCL 240

30% for TCL 024-105

Input frequency 47–63 Hz

Harmonic limits EN 61000-3-2, Class A

Input current at full load (typ.) (115 VAC / 230 VAC) TCL 024 models: 0.35 A / 0.2 A

TCL 060 models: 1.2 A / 0.6 A

TCL 120 models: 2.0 A / 1.0 A

TCL 240 model: 3.3 A / 1.7 A

Recommended circuit breaker TCL 240 model: 10 A (characteristic C or slow blow fuse)

all other models: 5 A (characteristic C or slow blow fuse)

Output Specifications

Output voltage adjustable range 5.1 VDC model: 5.0 – 5.25 VDC

(potentiometer on frontpanel) 12 VDC models: 12 – 15 VDC (12 - 16 VDC for TCL 024-112)

24 VDC models: 24 – 28 VDC

48 VDC models: 48 – 56 VDC

Output regulation (10 to 90% load variation) 2.5 % (1 % for TCL 60-112)

Ripple and noise (20MHz bandwidth) <50 mV pk-pk

Electronic short circuit protection current limitation at 120 % typ.

(constant current, automatic recovery

TCL 24 models: foldback, automatic recovery)

Parallel operation output current characteristic suitable for

parallel operation of max. 5 units

(not for TCL 240-124)

Overvoltage protection, trigger point 5.1 VDC model: <6.5 VDC

12/24 VDC models: <40 VDC

48 VDC models: <60 VDC

Hold-up time (115 VAC / 230 VAC) min. 15 ms / min. 125 ms

TCL 240 model: min. 15 ms / min. 40 ms

Power OK signal (TCL 60, 120 & 240 models only) trigger output signal

point (reference to – Vout)

12 VDC models: >11V 11.0 V ±1.0 V / 60 mA max.

24 VDC models: >22V 22.0 V ±2.0 V / 30 mA max.

48 VDC models: >44V 44.0 V ±4.0 V / 15 mA max.

General Specifications

Temperature ranges – Operating –10°C to +70°C max.

– Storage (non operating) –25°C to +85°C

Temperature derating – at 187...264 VAC or 265...375 VDC operation 1.7 %/K above +50°C

– at 93...132 VAC or 130...187 VDC operation 1.1 %/K above +40°C

– at 85...130 VDC operation 1.3 %/K above +30°C

Humidity (non condensing) 95 % rel. H max.

Temperature coefficient 0.02 %/K

Switching frequency 55 – 180 kHz depending on load

(frequency modulation)

Efficiency 88 % typ.

Isolation voltage – I/O isolation voltage (60 s) 3000 VAC
