www.tracopower.com Page 5 of 6
Industrial Power Supplies
TCL Series 24 to 240 Watt
TCL 60 models
Weight: 265 g (9.4 oz)
Output Input
1 +Vout 1 AC Ground
2 +Vout 2 Neutral
3 –Vout 3 Live
4 –Vout
5 Power OK
75.0 (2.95)
100.0
(3.94)
3.2
(0.13)
45
(1.77)
DC-ON LED
Output voltage
adjust
OUTPUT
1 2 3 4 5
INPUT
1 2 3
TCL 120 models
Weight: 440 g (15.5 oz)
Output Input
1 +Vout 1 AC Ground
2 +Vout 2 Neutral
3 –Vout 3 Live
4 –Vout
5 Power OK
75.0 (2.95)
100.0
(3.94)
3.2 (0.13)
85
(3.35)
DC-ON LED
Output voltage
adjust
OUTPUT
1 2 3 4 5
INPUT
1 2 3
DIN rail mounting hooks 20mm (0.79) wide
Dimensions in [mm], ( ) = Inch
Tolerances: ±0.5 mm (±0.02)
Case Dimensions
