TRACO POWER TCL-REM240 [6/6] Industrial power supplies
![TRACO POWER TCL-REM240 [6/6] Industrial power supplies](/views2/1709133/page6/bg6.png)
Page 6 of 6
Specifications can be changed without notice! Make sure you are using the latest documentation, downloadable at www.tracopower.com
www.tracopower.com
Industrial Power Supplies
TCL Series 24 to 240 Watt
Wall Mounting Bracket
Instead on a DIN-rail, the modules can be
also mounted on a chassis or wall with help of a
mounting bracket which is supplied as standard
with each power supply
Rev. July 31, 2019
110 (4.33)
125
(4.92)
85 (3.35)
DC-ON LED
Output voltage
adjust
OUTPUT
1 2 3 4 5
INPUT
1 2 3
Weight: 950 g (33.5 oz)
Output Input
1 +Vout 1 AC Ground
2 +Vout 2 Neutral
3 –Vout 3 Live
4 –Vout
5 Power OK
TCL 240 model
Case Dimensions
Dimensions in [mm], ( ) = Inch
Tolerances: ±0.5 mm (±0.02)
