AC/DC Industrial Power Supply

TIB 120 Series, 120 Watt

•

Slim profile, for DIN-rail mounting

•

Alternative side-mounting for flat panels

•

High power factor by active power

correction

•

Very high efficiency up to 94%

•

Back power immunity

•

150% peak current for 4 s

•

Operating temperature range: –40°C to

+70°C max.

•

Adjustable output voltage

•

Short circuit and overload protection

•

3 year product warranty

IEC 60950-1

UL 60950-1

UL 508

This generation of DIN-rail power supplies combines the most efficient circuit

topology with optimized cost/performance ratio for industrial environments and

for electrical control cabinets. They have a very high efficiency of up to 94.0%

which allows a very slim package design. The output voltage is adjustable from

–2% to +17%. The case offers the potentially useful feature to fix the DIN-rail

clip to the side wall for the mounting inside flat panels. Over a period of mini-

mum 4 seconds they can operate with a boost power of 150%. The boost pow-

er facilitates the activation of stepper motors, solenoids or actuators. The units

operate with a high power factor of up to 97% by active power factor correc-

tion which also keeps the input inrush current low. The TIB series are also avail-

able with other nominal power of 80, 240 or 480 Watt (+50% boost power).

They come with the safety standard approvals for IEC/EN 60950-1, UL

60950-1 and UL 508.

Models

Order Code

Output Power

max.

Output Voltage

nom. (adjustable)

Output Current

max.

Output Current

peak

Efficiency

typ.

TIB 120-112

120 W

12 VDC (11.8 - 15.0 VDC)

10'000 mA

15'000 mA

94 %

TIB 120-124

24 VDC (23.5 - 28.0 VDC)

5'000 mA

7'500 mA

94 %

TIB 120-148

48 VDC (47.0 - 56.0 VDC)

2'500 mA

3'750 mA

94 %

www.tracopower.com

April 9, 2019

Page 1 / 6
