TRACO POWER TIB 240-124 Datasheet онлайн
AC/DC Industrial Power Supply
TIB 240 Series, 240 Watt
•
Slim profile, for DIN-rail mounting
•
Alternative side-mounting for flat panels
•
High power factor by active power
correction
•
Very high efficiency up to 95%
•
Back power immunity
•
150% peak current for 4 s
•
Operating temperature range: –40°C to
+70°C max.
•
Adjustable output voltage
•
Short circuit and overload protection
•
3 year product warranty
IEC 60950-1
UL 60950-1
UL 508
This generation of DIN-rail power supplies combines the most efficient circuit
topology with optimized cost/performance ratio for industrial environments and
for electrical control cabinets. They have a very high efficiency of up to 95.0%
which allows a very slim package design. The output voltage is adjustable from
–2% to +17%. The case offers the potentially useful feature to fix the DIN-rail
clip to the side wall for the mounting inside flat panels. Over a period of mini-
mum 4 seconds they can operate with a boost power of 150%. The boost pow-
er facilitates the activation of stepper motors, solenoids or actuators. The units
operate with a high power factor of up to 98% by active power factor correc-
tion which also keeps the input inrush current low. The TIB series are also avail-
able with other nominal power of 80, 120 or 480 Watt (+50% boost power).
They come with the safety standard approvals for IEC/EN 60950-1, UL
60950-1 and UL 508.
Models
Order Code
Output Power
max.
Output Voltage
nom. (adjustable)
Output Current
max.
Output Current
peak
Efficiency
typ.
TIB 240-124
240 W
24 VDC (23.5 - 28.0 VDC)
10'000 mA
15'000 mA
95 %
TIB 240-148
48 VDC (47.0 - 56.0 VDC)
5'000 mA
7'500 mA
95 %
www.tracopower.com
April 9, 2019
Page 1 / 6
