TRACO POWER TIB 240-124 [4/6] Tib 240 series 240 watt
![TRACO POWER TIB 240-124 [4/6] Tib 240 series 240 watt](/views2/1709206/page4/bg4.png)
Leakage Current
- Earth Leakage Current
3500 µA max.
- Touch Current
310 µA max.
Reliability
- Calculated MTBF
1'300'000 h (IEC 61709)
Environment
- Vibration
EN 61373
IEC 60068-2-6
3 axis, sine sweep, 10 - 55 Hz, 2 g, 11 oct/min
- Mechanical Shock
EN 61373
IEC 60068-2-27
3 axis, 25 g half sine, 11 ms shock
Housing Material
Aluminium (Chassis)
Stainless Steel (Cover)
Connection Type
Screw Terminal
Mounting
- DIN Rail
For DIN-rails as per EN 50022-35×15/7.5
Weight
643 g
Thermal Impedance
0.95 K/W
Power Back Immunity
24 VDC model:
35 V max.
48 VDC model:
60 V max.
When external voltage is supplied above set out-
put voltage and below OVP threshold, the power
supply will function normally without switch off or
destruction, even if external voltage is applied
continuously.
Power OK Signal
Relay Output
- Trigger Threshold
24 VDC model:
OK: 22.5 VDC, Off: 21.5 VDC
48 VDC model:
OK: 45 VDC, Off: 43 VDC
- Power OK
Relay contact closed
- Power Off
Relay contact open
- Pin Specifications
30 VDC / 1 A max.
Status Indicator
Also indicated by green LEDs: front and side
Environmental Compliance
- Reach
www.tracopower.com/info/reach-declaration.pdf
- RoHS
www.tracopower.com/info/rohs-declaration.pdf
Supporting Documents
Overview Link (for additional Documents)
www.tracopower.com/overview/tib240
TIB 240 Series, 240 Watt
All specifications valid at nominal input voltage, full load and +25°C after warm-up time unless otherwise stated.
www.tracopower.com
April 9, 2019
Page 4 / 6
