Power Derating
- High Temperature
2 %/K above 60°C (at standard operation)
3 %/K above 60°C (at peak power mode)
- Low Input Voltage
3 %/V below 90 VAC (at standard operation)
1.5 %/V below 100 VAC (at peak power mode)
Cooling System
Natural convection (no internal fan, 20 LFM)
Altitude During Operation
2000 m max.
Switching Frequency
70 - 100 kHz (PWM)
Insulation System
Reinforced Insulation
Isolation Test Voltage
- Input to Output, 60 s
4'250 VDC
- Input to Case or PE, 60 s
1'500 VDC
- Output to Case or PE, 60 s
750 VDC
Creepage
- Input to Output
8 mm min.
- Input to Case or PE
4 mm min.
- Output to Case or PE
1.5 mm min.
Clearance
- Input to Output
8 mm min.
- Input to Case or PE
4 mm min.
- Output to Case or PE
1.5 mm min.
Leakage Current
- Earth Leakage Current
3500 µA max.
- Touch Current
310 µA max.
Reliability
- Calculated MTBF
1'450'000 h (IEC 61709)
Environment
- Vibration
EN 61373
IEC 60068-2-6
3 axis, sine sweep, 10 - 55 Hz, 2 g, 11 oct/min
- Mechanical Shock
EN 61373
IEC 60068-2-27
3 axis, 25 g half sine, 11 ms shock
Housing Material
Aluminium (Chassis)
Stainless Steel (Cover)
Connection Type
Screw Terminal
Mounting
- DIN Rail
For DIN-rails as per EN 50022-35×15/7.5
Weight
461 g
Thermal Impedance
0.8 K/W
Power Back Immunity
12 VDC model:
19 V max.
24 VDC model:
35 V max.
48 VDC model:
60 V max.
When external voltage is supplied above set out-
put voltage and below OVP threshold, the power
supply will function normally without switch off or
destruction, even if external voltage is applied
continuously.
Power OK Signal
Relay Output
- Trigger Threshold
12 VDC model:
OK: 10.9 VDC, Off: 10.7 VDC
24 VDC model:
OK: 22.5 VDC, Off: 21.5 VDC
48 VDC model:
OK: 45 VDC, Off: 43 VDC
- Power OK
Relay contact closed
- Power Off
Relay contact open
- Pin Specifications
30 VDC / 1 A max.
Status Indicator
Also indicated by green LEDs: front and side
Environmental Compliance
- Reach
www.tracopower.com/info/reach-declaration.pdf
- RoHS
www.tracopower.com/info/rohs-declaration.pdf
Supporting Documents
Overview Link (for additional Documents)
www.tracopower.com/overview/tib120-ex
TIB 120-EX Series, 120 Watt
All specifications valid at nominal input voltage, full load and +25°C after warm-up time unless otherwise stated.
www.tracopower.com
April 9, 2019
Page 4 / 6
