- 5 -
1.4 Specification
Model FSD-804P
Hardware Specification
Network Connector 8-Port RJ-45 for 10/100Base-TX
PoE Inject Port 4-Port with PoE injector function, Port-1 to Port-4
LED Display
One power,
1-4 port PoE in-use, LNK/ACT
5-8 port LNK/ACT
Switch Architecture Store and Forward switch architecture
Switch Fabric 1.6Gbps
MAC Address 1K MAC address table with Auto learning function
Throughput 1.19Mbps
Remote power feeding
End-point insert type and compatible with IEEE 802.3af
Per port feeding power: 48V DC, 15.4W, 350mA (Maximum)
(Pin 1, 2, 3, 6)
Power AC 100~240V, 50/60Hz,
Power Consumption Max. 65 watts / 221 BTU
Dimension (W x D x H) 217 x 135 x 43 mm
Weight 1.0 kg
Power over Ethernet
PoE Standard IEEE 802.3af Power over Ethernet / PSE
PoE Power Supply Type End-Span
PoE Power Output Per Port 48V DC, 350mA . Max. 15.4 watts
Power Pin Assignment 1/2(+), 3/6(-)
Power Budget
55 watts
Standard Conformance
EMI Safety FCC Class A, CE
Operating environment 0~40 degree C, 10%~95%RH
Storage environment -40 ~70 degree C, 95% RH
Operating Humidity
5% to 90% , relative humidity, non-condensing
Storage Humidity
5% to 90% , relative humidity, non-condensing
Standard Compliance IEEE 802.3
IEEE 802.3u
IEEE 802.3x
IEEE 802.3af
Ethernet
Fast Ethernet
Flow Control
Power over Ethernet
