1.3 MOTHERBOARD FEATURES
H61MGB / H61MLB H61MHB
CPU
Socket 1155
Intel Core i7 / i5 / i3/ Pentium processor
Supports Execute Disable Bit / Enhanced Intel
SpeedStep® / Intel Architecture-64 / Extended
Memory 64 Technology / Virtualization
Technology
Socket 1155
Intel Core i7 / i5 / i3/ Pentium processor
Supports Execute Disable Bit / Enhanced Intel
SpeedStep® / Intel Architecture-64 / Extended
Memory 64 Technology / Virtualization
Technology
Chipset
Intel H61 Intel H61
Super I/O
ITE 8728
Provides the most commonly used legacy Super
I/O functionality.
Low Pin Count Interface
Environment Control initiatives,
Hardware Monitor Controller
Fan Speed Controller
ITE's "Smart Guardian" function
ITE 8728
Provides the most commonly used legacy Super
I/O functionality.
Low Pin Count Interface
Environment Control initiatives,
Hardware Monitor Controller
Fan Speed Controller
ITE's "Smart Guardian" function
Main Memory
DIMM Slots x 2
Each DIMM supports
512MB/1GB/2GB/4GB/8GB DDR3
Max Memory Capacity 16GB
Dual Channel Mode DDR3 memory module
Supports DDR3 1333/1066/1600 (depending
on CPU)
Registered DIMM and ECC DIMM is not
supported
DIMM Slots x 2
Each DIMM supports
512MB/1GB/2GB/4GB/8GB DDR3
Max Memory Capacity 16GB
Dual Channel Mode DDR3 memory module
Supports DDR3 1333/1066/1600 (depending
on CPU)
Registered DIMM and ECC DIMM is not
supported
SATA 2
Integrated Serial ATA Controller
Data transfer rates up to 3.0 Gb/s.
SATA Version 2.0 specification compliant
Integrated Serial ATA Controller
Data transfer rates up to 3.0 Gb/s.
SATA Version 2.0 specification compliant
LAN
AR8151 (H61MGB)
10 / 100 Mb/s / 1Gb/s auto negotiation
AR8152 (H61MLB)
10 / 100 Mb/s auto negotiation
AR8151
10 / 100 Mb/s / 1Gb/s auto negotiation
Sound Codec
VT1708B/ALC662
5.1 channels audio out
High Definition Audio
VT1708B/ALC662
5.1 channels audio out
High Definition Audio
PCI-E Gen3x16 slot x1
(depending on CPU)
PCI-E Gen3x16 slot x1
(depending on CPU)
PCI Express Gen2 x1 Slot x1 PCI Express Gen2 x1 Slot x1
Slots
PCI Slot x2 PCI Slot x2
Printer Port Connector x1 Printer Port Connector x1
On Board
Serial Port Connector x1 Serial Port Connector x1
