Motherboard Manual
4
1.5 MOTHERBOARD LAYOUT
USB_
KBMS1
VGA1
DVI1
RJ45USB1
AUDIO1
ATXPWR2
CODEC
LAN
Super
I/O
BAT1
PCI1
PCI2
PEX16_1
PEX1_1
F_AUDIO1 J_PRINT1 J_COM1
F_USB1 F_USB2
SYS_FAN1
JCMOS1
PAN EL1
BIOS
H61
SATA4
SATA2
SATA3
SATA1
ATXPWR1
Socket 1155
CPU1
CPU_FAN1
DDR3_B1
DDR3_A1
HDMI1
(H61MHB)
Note: ■ represents the 1
st
pin.
