Chapter 2 Hardware Installation

Before you proceed with the installation, it is necessary that you have enough information about the

WAP-4033PE.

1. Locate an optimum location for the WAP-4033PE. The best place for your WAP-4033PE is

usually at the center of your wireless network, with line of sight to all of your mobile stations.

2. Assemble the antenna to WAP-4033PE. Try to place them to a position that can best cover your

wireless network. The antenna’s position will enhance the receiving sensitivity.

3. Connect RJ-45 cable to WAP-4033PE. Connect this WAP-4033PE to your LAN switch/hub or a

single PC. If the connected device is IEEE802.3af compliant switch, the WAP-4033PE will power

on. You will not need to plug-in the power adapter in next step.

4. Plug in power adapter and connect to power source. After power on, WAP-4033PE will start to

work.

Note:

ONLY use the power adapter supplied with the WAP-4033PE. Otherwise, the product may

be damaged. If you want to reset your WAP-4033PE to default settings, press the Reset

button 5 second. Then release the button and wait for 10 seconds for rebooting.
