TPower X58/TPower X58A BIOS Manual
10
Intel (R) HT Technology
Hyper Threading Technology can improve performance by splitting instructions into
multiple streams.
Options: Enabled (Default) / Disabled
Active Processor Cores
This item allows you to set the number of cores to enable in each processor package.
Options: All (Default) / 1 / 2
A20M
Options: Disabled (Default) / Enabled
SuperIO Conf iguration
BIOS SETUP UTILITY
Advanced
vxx.xx (C)Copyright 1985-200x, American Megatre nds, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
Allows BIOS to Enable
or Disable Floppy
Controller
Configure ITE8720 Super IO Chipset
Onboard Floppy Controller [Enabled]
Keyboard PowerOn [Disabled]
Mouse PowerOn [Disabled]
Restore on AC Power Loss by IO[Power Off]
Onboard Floppy Controller
Select enabled if your system has a floppy disk controller (FDC) installed on the
system board and you wish to use it. If you installed another FDC or the system uses
no floppy drive, select disabled in this field.
Options: Enabled (Default) / Disabled
