TPower X58/TPower X58A BIOS Manual
4
IDE/SATA Configuration
The BIOS will automatically detect the presence of IDE/SATA devices. There is a
sub-menu for each IDE/SATA device. Select a device and press <Enter> to enter
the sub-menu of detailed options.
BIOS SETUP UTILITY
Main
vxx.xx (C)Copyright 198 5-200x, American Megatrends, Inc.
Select Screen
Select Item
Go to Sub Scr een
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
IDE/SATA Confugura tion
Configure SATA#1 as [IDE]
> SATA 1 Device
> SATA 2 Device
> SATA 3 Device
> SATA 4 Device
> SATA 5 Device
> SATA 6 Device
> Primary IDE Slav e
SATA#2 Configurati on [Enhanced]
Max Ports on SATA# 1 [6 Ports]
SATA#1 Configurati on [Compatible]
> AHCI Configurati on
> ESATA 1 Device
> ESATA 2 Device
> Primary IDE Mast er
Options
Disabled
Compatible
Enhanced
SATA#1 Configuration
This item allows you to control the onboard SATA controller.
Options: Compatible (Default) / Disabled / Enhanced
Configure SATA#1 as
This item allows you to choose the SATA operation mode.
Options: IDE (Default) / RAID / AHCI
SATA#2 Configuration
This item allows you to control the onboard SATA controller.
Options: Enhanced (Default) / Disabled
Max Ports on SATA#1
This item appears only when SATA mode is set to AHCI/RAID.
Options: 6 Ports (Default) / 4 Ports
