TPower X58/TPower X58A BIOS Manual
20
Onboard PCIE Giga LAN (TPower X58 Only)
This item allows you to control the onboard LAN.
Options: Auto (Default) / Enabled / Disabled
Onboard LAN Boot Rom (TPower X58 Only)
This item allows you to select the Onboard LAN Boot ROM.
Options: Disabled (Default) / Enabled
Port 1 MAC ID Information
This item shows the LAN MAC ID.
Port 2 MAC ID Information (TPower X58 Only)
This item shows the LAN MAC ID.
Intel VT-d Configuration
BIOS SETUP UTILITY
Advanced
vxx.xx (C)Copyright 1985-200x, Amer ican Megatre nds, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
Intel VT-d [ Disabled]
Options
Disabled
Enabled
Intel VT-d
Intel(R) Virtualization Technology for Directed I/O (VT-d) provides hardware
assists for virtualization, improving security, reliability, and performance of I/O
devices in virtualized environment.
Options: Disabled (Default) / Enabled
