Motherboard Manual
2
1.3 MOTHERBOARD FEATURES
TP45D2- A7 TP43D2- A7
CPU
LGA 775
Intel Core2Duo / Core2Quad /
Pent iu m Dual-Core / C e leron Du al-Core /
Celeron 4xx processor
Supports Execute Disable Bit / Enhanced Intel
SpeedStep® / Intel Architecture-64 / Extended
Memory 64 Technology / Virtualization
Technology
LGA 775
Intel Core2Duo / Core2Quad /
Pent iu m Dual-Core / C eleron Du al-Core /
Celeron 4xx processor
Supports Execute Disable Bit / Enhanced Intel
SpeedStep® / Intel Architecture-64 / Extended
Memory 64 Technology / Virtualization
Technology
FSB Support 800 / 1066 / 1333 / 1600 MHz Support 800 / 1066 / 1333 / 1600 MHz
Chipset
Intel P45
Intel ICH1 0
Intel P43
Intel ICH1 0
Super I/O
ITE 8718F
Provides the most commonly used legacy Super
I/O functionality.
Low Pin Count Interface
Environment Control in it iatives,
Hardware Monitor Controller
Fan Sp eed Contro ller
ITE's "Smart Guardian" funct ion
ITE 8718F
Provides the most commonly used legacy Super
I/O functionality.
Low Pin Count Interface
Environment Control in it iatives,
Hardware Monitor Controller
Fan Sp eed Contro ller
ITE's "Smart Guardian" funct ion
Main
Memory
DIMM Slots x 4
Each DIMM supports 256MB / 512MB / 1GB /
2GB DDR2
Max Memory Capicity 8GB
Dual Channel Mode DDR2 memory module
Supports DDR2 1066 / 800 / 667
Registered DIMM and ECC DIMM is not
supported
DIMM Slots x 4
Each DIMM supports 256MB / 512MB / 1GB /
2GB DDR2
Max Memory Capicity 8GB
Dual Channel Mode DDR2 memory module
Supports DDR2 1066 / 800 / 667
Registered DIMM and ECC DIMM is not
supported
IDE
JMicro JMB368
Ultra DMA 33 / 66 / 100 / 133 Bus Master Mode
supports PIO Mode 0~4
JMicro JMB368
Ultra DMA 33 / 66 / 100 / 133 Bus Master Mode
supports PIO Mode 0~4
SATA 2
Integrated Serial ATA Controller
Data transfer rates up to 3.0 Gb/s.
SATA Vers ion 2.0 specificat ion co mp liant
Integrated Serial ATA Controller
Data transfer rates up to 3.0 Gb/s.
SATA Vers ion 2.0 specificat ion co mp liant
LAN
Realtek RTL 8111C
10 / 100 Mb/s / 1Gb/s auto negotiation
Half / Full duplex capability
Realtek RTL 8111C
10 / 100 Mb/s / 1Gb/s auto negotiation
Half / Full duplex capability
Sound
Codec
ALC662
5.1 channels audio out
High Definition Audio
ALC662
5.1 channels audio out
High Definition Audio
