TP45D2-A7/TP43D2-A7
49
TP45D2- A7 TP43D2- A7
Soporte de
sonido HD
ALC662
Soporte de sonido de Alta Definición
Salida de sonido de 5.1 canales
ALC662
Soporte de sonido de Alta Definición
Salida de sonido de 5.1 canales
Ranura PCI X3 Ranura PCI X3
Ranura PCI Express Gen2 x16 X1 Ranura PCI Express Gen2 x16 X1
Ranuras
Ranura PCI express x 1 X2 Ranura PCI express x 1 X2
Conector disco flexible X1 Conector disco flexible X1
Conector Puerto de impresora X1 Conector Puerto de impresora X1
Puerto serie X1 Puerto serie X1
Conector IDE X1 Conector IDE X1
Conector SATA X6 Conector SATA X6
Conector de panel frontal X1 Conector de panel frontal X1
Conector de sonido frontal X1 Conector de sonido frontal X1
Conector de entrada de CD X1 Conector de entrada de CD X1
Cabecera de ventilador de CPU X1 Cabecera de ventilador de CPU X1
Cabecera de ventilador de sistema X2 Cabecera de ventilador de sistema X2
Cabecera de borrado de CMOS X1 Cabecera de borrado de CMOS X1
Conector USB X3 Conector USB X3
Conector de alimentación X1
(24 patillas)
Conector de alimentación X1
(24 patillas)
Conectores
en placa
Conector de alimentación X2
(4 patillas)
Conector de alimentación X2
(4 patillas)
Panel
trasero de
E/S
Tec l ad o PS /2 X 1
Ratón PS/2 X1
Puerto de red local X1
Puerto USB X6
Conector de sonido X3
Tec l ad o PS /2 X 1
Ratón PS/2 X1
Puerto de red local X1
Puerto USB X6
Conector de sonido X3
Ta mañ o d e
la placa
220 mm. (A) X 305 Mm. (H) 220 mm. (A) X 305 Mm. (H)
Soporte de
sistema
operativo
Windows 2000 / XP / VISTA
Biostar se reserva el derecho de añadir o retirar
el soporte de cualquier SO con o sin aviso previo.
Windows 2000 / XP / VISTA
Biostar se reserva el derecho de añadir o retirar
el soporte de cualquier SO con o sin aviso previo.
