Planet GT-706A15 [12/18] Led indication

LED INDICATION

LED Color Description

Green Lit: when the fiber port run in fix

1000Mbps and packet is travel-

TP/ ACT Green Lit: when the packet is traveling.

Green Lit: when fiber connection is good.

TP/LNK Green Lit: when TP connection is good.

FDX Green Lit: when the TP port runs in

1000Mbps Full duplex

PWR Green Lit: when +5VDC power detected

Table 8-1: LED indication of GT-70x
